The MAX14824 IO-Link master transceiver is IO-Link version 1.1/1.0 physical layer compliant with highly integrated 5V and 3.3V linear regulators, configurable outputs (push-pull, high side or low side), auxiliary digital input, 300mA C/Q output drive, and reverse-polarity/short-circuit protection, all in a small 4mm x 4mm, industrial-friendly TQFN package. The MAXREFDES79# IO-Link master consists of 4 main blocks: four IO-Link master transceivers, step-down converters, microcontroller, and USB connection as shown in Figure 1. The MAXREFDES79# reference design block diagram. Figure 1 shows the system block diagram.įigure 1.
Designbox serial software#
The MAXREFDES79# design consists of four industry-standard Maxim Integrated IO-Link master transceivers (MAX14824), two efficient industrial step-down converters (MAX15062B, MAX17552), and an STMicroelectronics 32-bit ARM Cortex M4 microcontroller (STM32F4) utilizing TEConcept’s TC Tool software and IO-Link master stack. It is a version 1.1-compliant IO-Link master reference design. Maxim Integrated and TEConcept collaborated in designing the MAXREFDES79# IO-Link master using TEConcept’s IO-Link master stack.
Designbox serial manual#
IO-Link Device Descriptor (IODD) files completely define the device and eliminate manual parameterization. The 3-wire protocol is also backwards compatible with binary sensors and actuators that use standard input output (SIO).
IO-Link is a Single-drop Digital Communication Interface (SDCI), which means there can only be one sensor or actuator per port. IO-Link can function directly from the PLC or can be converted from all standard field busses to IO-Link through a gateway, quickly making it the defacto standard for universally communicating with smart sensors and actuators. 1 IO-Link finally standardizes interoperability of industrial equipment from all over the world.
Designbox serial serial#
IO-Link is the first open, field bus agnostic, low-cost, point-to-point serial communication protocol, used for communicating with sensors and actuators, that has been adopted as an international standard (IEC 61131-9).
Designbox serial windows#
A Micro-USB connector underneath the enclosure allows for quick connectivity to a Windows ® PC. An AC-to-DC (24VDC/1A) power-supply cube is capable of providing greater than 200mA simultaneously to each port and greater than four times that amount if the other ports are unused. The reference design has four robust female M12 connectors, the most common connector used for IO-Link, and ships with two black IO-Link cables to quickly connect to IO-Link compatible sensors and actuators. Green and RGB LEDs located on the side of the cylindrical enclosure provide power and communication status, respectively. Four IO-Link ports allow for simultaneous testing of four different sensors (or actuators). This design uses TEConcept’s IO-Link master stack and is both an IO-Link master reference design as well as an IO-Link sensor/actuator development and test system. Use the high efficiency and large air volume axial fan, with low noise and energy saving.The MAXREFDES79# is the world’s first public and fully IO-Link ®-compliant, 4-port IO-Link master reference design. Proper structure, accurate and reliable operating system for the air cooled condensing unit. evaporating temperature:-45✬-+15☌, run steady under the ambient temperature +43✬.ĥ. Air cooled condensing unit refrigerating capacity ranks from 0.2KW to 29KW. 3.Every part of units is best in corrosion protection.Ĥ.
